Polyunsaturated fatty acids (PUFAs) are one of fatty acid that have two or more double bonds and exist as cis- or trans-isoform following by structure of double bonds. The follicles, oocytes, and spermatozoa contain large amount of PUFAs (Homa & Brown, 1992). Especially, biochemical composition of follicular fluid determines microenvironment in follicles for oocyte growth and maturation (Khalil et al., 2013) and PUFAs influence to oocyte maturation, fertilization, and subsequent development through altering the biochemical composition of follicular fluid (Bilby et al., 2006). Fouladi-Nashta et al. (2009) had reported that fatty acid composition in granulosa cells were altered by dietary or supplementation in culture medium, and it had influence to oocyte maturation, and subsequent development in in vivo and in vitro. Omega-3, a one of PUFAs, regulates variety of reproductive function in mammals (Wathes et al., 2007). Quality of oocyte and embryo were enhanced by their type and ratio in composition of fatty acid (Wonnacott et al., 2010).
Alpha-linolenic acid (ALA; n-3 18:3), a one of omega-3 fatty acid, is mainly contained in chloroplast of plant (Marei et al., 2009). As an essential fatty acid, ALA was not synthesized in mammalian body including human, cow, and pig. And it must be supplied from foods (Sturmey et al., 2009). Ambrose et al. (2006) had reported that dietary ALA in cows increased the size of pre-ovulatory follicles and reduced pregnancy loss. Also, supplementation of ALA during bovine oocyte maturation decreased intracellular reactive oxygen species (ROS) level (Marei et al., 2012). Many studies that are involved with effect of ALA by dietary or in vitro supplement on female reproductive events in cows were reported. However, a few studies in pigs were reported.
Pigs are important animal not only for agriculture, but also for research of human disease as a disease model animal (Pratt et al., 2006). Because pigs have genetic, anatomical, and physiological similarity compared to human, it was used in various field of research for disease model and production of transgenic animals (Lin et al., 2009). Successful in vitro production (IVP) technique of porcine embryos were required for various researches, however, quality of embryo derived from IVP in pigs was lower than embryo derived from in vivo (Kitagawa et al., 2004). In in vitro environment, porcine oocytes have a lower maturation rate in both of nuclear and cytoplasm than in vivo mature oocytes (Kim et al., 2013; Elahi et al., 2016). To improve these problems, many researchers supplied the antioxidants and fatty acid into maturation or culture medium of oocytes, and fatty acids play a role as an energy source of oocytes, storage of energy for metabolism, and embryo development (McKeegan & Sturmey, 2011). Based on these studies, we expected that function of ALA positively influenced to oocyte maturation and subsequent development. Therefore, the aim of this study was to investigate the effect of additional ALA during in vitro maturation (IVM) and culture (IVC) on nuclear maturation and embryo development in pigs.
Materials and methods
All procedures that involved the use of animals were approved by the Kangwon National University Institutional Animal Care and Use Committee (KIACUC-09-0139). Ovaries were collected from slaughtered gilts at local slaughter house and transferred into the laboratory in 0.9% (w/v) sterilized saline within 2 h. The cumulus-oocyte complexes (COCs) were aspirated from antral follicles with 3-6 mm in diameter using 10 cc syringe with 18-gauge needle. After aspiration, COCs with homogeneous cytoplasm and compact cumulus layer were selected and incubated in medium-199 (Invitrogen, MA, USA) containing 10% (v/v) porcine follicular fluid (pFF), 10 IU/mL human chorionic gonadotropin (hCG; Intervet), 10 ng/mL luteinizing hormone (LH; Sigma-Aldrich, St. Louis, MO, USA), 10 ng/mL follicle stimulating hormone (FSH; Sigma-Al-drich) and 10 ng/mL epidermal growth factor (EGF; Sigma-Aldrich) with ALA, which was diluted using ethanol (final concentration: 0.9%), at 38.5℃, 5% CO2 condition for 22 h. Because hCG is known that it can improve cytoplasmic maturation (Kątska-Książkiewicz, 2006), we added hCG into IVM medium. Then, they were subsequently incubated using hormone-free medium-199 with ALA at 38.5℃, 5% CO2 condition for 22 h.
Aceto-orcein stain method was used to evaluate nuclear maturation stage of porcine oocytes that were incubated with different concentration of ALA during IVM. Hyaluronidase was treated into mature COCs and cumulus cells were removed by gentle pipetting using pasture pipette. Denuded oocytes were fixed in acetic alcohol solution (acetic acid:ethanol; 1:3; v/v) for 48 h, at room temperature (RT). And oocytes were was stained by 1% (w/v) aceto-orcein at RT for 7 min. The morphology of nuclear was observed under light microscope. Metaphase II (MII) stage oocytes were classified as mature oocyte.
Mature COCs were treated by 0.1% (v/v) hyaluronidase for reduction of binding between cumulus cells. And they placed in 50 µL drop of modified tris-buffered medium (mTBM) containing 0.2% (w/v) bovine serum albumin (BSA; Sigma-Aldrich). For hyperactivation of spermatozoa, fresh boar semen were placed in mTBM containing 0.4% (w/v) BSA and 0.39 mg/mL caffeine (Sigma-Aldrich) and they diluted at a final concentration of 6×105 spermatozoa/mL. Activated sperm inseminated into prepared COCs and co-incubated at 38.5℃, 5% CO2 condition for 6 h.
After fertilization, cumulus cells and spermatozoa surrounding zona pellucida of fertilized oocytes were completely removed by gentle pipetting and 70-80 embryos were cultured in 4-well dishes (SPL Life Science, Korea) with 650 µL porcine zygote medium-3 (PZM-3) containing 0.3% (w/v) BSA (Sigma-aldrich) at 38.5℃, 5% CO2 condition for 48 h (early-embryogenesis). Then, culture medium was exchanged to fresh medium and subsequently incubated for 120 h in same culture condition (late-embryogenesis). For comparison of embryo development between short- and long-term ALA treatment at 168 h after IVF, cleavage rate, blastocyst formation, and total cell number of blastocyst were checked at 168 h after IVF.
To evaluate total cell number, blastocyst stage embryos were fixed in 4% (v/v) paraformaldehyde at room temperature (RT) for 3 min. And nuclear of blastocyst was stained by 1 µg/mL bisbenzimide H 33342 trihydrochloride (Hoechst 33342; Sigma-Aldrich) at RT for 30 min in dark room and observed using fluorescent microscope.
All numerical data representing each parameter were analyzed using the Statistical Analysis System Software (SAS, version 9.4). Data were presented means ± SEM and comparisons among treatment groups were conducted by least significant difference (LSD) tests using a generalized linear model (GLM) in the SAS package. A value of p<0.05 was considered to indicate a statistically significant difference.
To evaluate effect of ALA on nuclear maturation of oocytes, porcine oocytes were incubated using IVM medium with different concentration of ALA (0, 25, 50, and 100 µM; Sigma-aldrich) for 44 h and stage of nuclear maturation was observed using aceto-orcein stain method. In experiment 1, 50 COCs were used in each replication and total 3 replication were conducted.
Based on result in experiment 1, mature oocytes with 50 µM ALA were fertilized and cultured using IVC medium containing different concentration of ALA (0, 25, 50, and 100 µM) for 48 h after fertilization (early-embryogenesis). Then, culture medium without ALA was exchanged and embryos were subsequently cultured for 120 h.
In pigs, the early embryos develop in oviduct and they are transported into the uterus at 48 h after fertilization. Therefore, we expected that embryo development was differently influenced before or after at 48 h after fertilization. To investigate the effect of ALA during embryogenesis, mature embryos with ALA were cultured in IVC medium with or without 25 µM ALA for 48 h and subsequently incubated using IVC medium with or without 25 µM ALA for 120 h. Treatment groups were named as following: T1, without ALA in early- and late-embryogenesis; T2, with ALA in late-embryo-genesis; T3, with ALA in early-embryogenesis; T4, with ALA in early- and late-embryogenesis.
The Effect of ALA during IVM on nuclear maturation of porcine oocytes was shown in Table 1. Mature oocytes, which are reached at MII stage, were increased by 50 μM ALA treatment (P<0.05), whereas 25 μM ALA did not influence. Treatment of 100 μM ALA reduced oocyte maturation compared to 50 μM ALA groups, however, there is no significant difference.
|ALA (μM)||No. of oocytes used for IVM (%)||No. of oocyte (%)|
|0||221||26 (17.3±1.8)a||124 (82.7±1.7)b|
|25||226||26 (17.3±1.3)a||124 (82.7±1.3)b|
|50||229||16 (10.7±1.8)b||134 (89.3±1.8)a|
Table 2 indicated the embryo development by different concentration of ALA during early-embryogenesis. The cleavage rate in 25 μM ALA-treated groups were significantly higher than other treatment groups (P<0.05). On the other hand, treatment of 50 and 100 μM ALA reduced cleavage rates compared to control group, especially, it was significantly decreased in 100 μM ALA group compared with control and 25 μM ALA groups (P<0.05). Beside, blastocyst formation and total cell number were not influenced by ALA treatment (Fig. 1).
|ALA (μM)||No. of oocytes used for IVF (%)||No. of embryo development to (%)|
|0||221||178 (80.5±0.1)b||15 (10.4±1.3)|
|25||226||199 (88.1±0.1)a||20 (12.1±2.1)|
|50||229||180 (78.6±0.3)bc||20 (12.0±1.7)|
|100||226||173 (76.5±1.7)c||14 ( 8.9±0.4)|
The effect of long- and/or short-supplement of ALA on embryo development were presented in Table 3 and Fig. 2. T2 and T3 treatment increased cleavage rate compared to T1, however, there was no significant difference. And cleavage rate in T4 group was significantly lower than T2 groups (P<0.05), whereas it was no difference with control and T2 groups. Similar to result in experiment 2, ALA treatment did not influence to blastocyst formation. And blastocysts in T4 treatment group had lower number of cells than T3 group (P<0.05).
Many researchers used pFF for improvement of porcine IVP system through imitation of in vivo environment. Oocyte maturation in in vivo environment was occurred in follicles that contain follicular fluids and influenced by nutrients in follicular fluid. And composition of follicular fluid are changed by dietary nutrients. Therefore, this study was conducted to investigate effect of additional ALA on nuclear maturation and embryo development in pigs. Our findings showed that nuclear maturation of porcine oocytes were enhanced by 50 µM ALA treatment, whereas it was reduced by treatment of 100 µM ALA. In addition, supplement of 25 µM ALA during early-embryogenesis icreased cleavage rate of embryo that were mature with 50 µM ALA, however, blastocyst formation and total cell number were not influenced by treatment of ALA. Interestingly, 25 µM ALA treatment during early-embryogenesis enhanced cleavage rate and blastocyst formation, on the contrary, ALA treatment during both of early- and late-embryogenesis decreased embryo development and quality.
Fatty acid is considered as potential metabolic substrate in oocyte and early stage embryo and required as energy source for metabolism in embryo during pre-implantation in pigs and cows (Sturmey et al., 2009). Wakefield et al. (2007) had reported that maternal supply of omega-3 PUFA influence to mature of oocyte through distribution of mitochondria, level of intracellular calcium, and increase of ROS during oocyte maturation in follicle. Also, cis-unsaturated fatty acid stimulates generation of ROS and lipid peroxidation in human spermatozoa (Aitken et al., 2006). These studies indicated that supplementation of fatty acids were associated with generation of ROS in various type of cells and it affected to cellular process such as oocyte maturation, embryo development, and survival via stimulation by ROS. ROS, which is produced by normal metabolism of the cell, is caused oxidative stress as a crucial signal molecule (Al-Gubory et al., 2010). Excessive ROS level in cells induce inactivation of enzymes, DNA fragmentation, dysfunction of mitochondria, and apoptosis (Kowaltowski & vercesi, 1999).
Exposure of ROS reduces the oocyte maturation, fertilization and embryo development both in vivo and in vitro. In mouse oocytes, exposure of citrinin toxin during maturation increased ROS generation and apoptosis, and decreased maturation rates and blastocyst formation (Wu et al., 2017). In results of present study, nuclear maturation of porcine oocytes were enhanced by 50 µM ALA treatment and these results were corresponded to research that was reported by Marei et al. (2009). However, Lee et al. (2016) had reported that nuclear maturation of porcine oocytes were enhanced by 100 µM ALA that was diluted by culture media including 0.4% BSA, epidermal growth factor, and insulin. Thus, we expected that different result might be attributed to dilution method of ALA and composition of culture media used in each experiment. During the porcine oocyte maturation, intracellular glutathione (GSH) was increased by treatment of ALA (Lee et al., 2016) and Marei et al. (2012) had reported that ALA treatment reduced ROS level in bovine oocyte. GSH plays an important role in prevent of damage by oxidative stress (Nagai, 2001). Based on these results, our results indicated that ALA treatment during porcine oocyte maturation might enhance the nuclear maturation via reduction of oxidative stress. In addition, reduced nuclear maturation of porcine and bovine oocyte by mitogen-activated protein kinase (MAPK) inhibitor during in vitro maturation was recovered by ALA treatment (Marei et al., 2009; Lee et al., 2016) and these results suggested that ALA was involved with signal pathway regarding to nuclear maturation of oocytes.
Supplementation of 50 µM ALA in IVM medium increased nuclear maturation of porcine oocytes, however, 100 µM ALA treatment reduced oocyte maturation during IVM. Similar to our findings, 100 and 200 µM ALA decreased nuclear maturation of bovine oocytes, whereas 50 µM ALA increased oocyte maturation (Marei et al., 2009). Wakefield et al. (2007) had reported that supply of omega-3 fatty acid by dietary increased ROS level in murine oocytes and these results suggested that excessive ALA suppressed oocyte maturation by inducing of oxidative stress.
Measurement of CO2 in rabbit embryos when cultured with palmitic acid during the development of rabbit embryos shows that embryos can oxidize fatty acids even in the single-cell stage, In particular, it was reported that the production of CO2 increased from the 4 cell stage (Khandoker & Tsujii,1998). This indicated that fatty acids added during embryonic development were used as an energy source (Sturmey et al., 2009), and thus the addition of 25 μM ALA during embryonic development in this study may have served as an energy source during embryonic development. However, treatment with 100 μM ALA suggests that oxidative stress may be induced in the oocyte and inhibit development of the embryo.
Lee et al. (2016) had reported that 100 μM ALA treatment during IVM of porcine oocytes enhanced embryonic development after parthenogenesis of oocytes. In present study, ALA was supplied into both of maturation and subsequent development process of porcine oocytes. Additional supplementation of 100 μM ALA during IVC of porcine embryo negatively affected to cleavage rate of embryo after IVF. These different results suggested that embryo development of porcine oocytes were influenced by period of ALA treatment and fertilization method. Interestingly, total cell number of control group in experiment 3 was decreased compare with control group in experiment 2. We expected that it was influenced by seasonal effect. Experiment 2 was conducted during winter, whereas experiment 3 was conducted during summer.
It is known that oxidative stress is a major obstacle to the development of embryos and that excessive ROS can negatively affect embryo development (Guerin et al., 2001). Antioxidants are added to reduce excessive ROS production during embryonic development, and antioxidants have been reported to be effective in embryonic development such as mice, pigs, and cows by lowering the ROS level in embryos (Takahashi, 2012). Lee et al. (2015) had reported that 200 μM γ-tocotrienol was reduced during embryonic development and decreased ROS and improved embryonic development. This is similar to the results of increased cleavage rates and total cell number in the T3 group treated with ALA during early embryonic development in this study. However, when 400 μM γ-tocotrienol was treated, the embryo apoptosis was increased as well as ROS in the embryo, This is similar to the results of the reduced cleavage rates and total cell number of blastocysts in the T4 group treated with ALA during both early and late embryonic development during after of fertilization development in this study, as a result, excessive ALA treatment had a negative effect on oocytes.
In this present study, supplementation of additional ALA in IVM and IVC medium enhanced nuclear maturation of oocyte and embryo development in pigs. However, high concentration of ALA (100 µM in IVM; 50 and 100 µM in IVC) negatively affect to oocyte maturation and embryo development. Therefore, our findings suggest that ALA could improve in vitro production systems of porcine embryo and additional ALA in dietary may enhanced reproductive performance of pigs.
