Original research paper

Loss of Aquaporin-3 in Placenta and Fetal Membranes Induces Growth Restriction in Mice

Min Joon Seo1,2,*, Ju Hyun Lim2,3,*, Dong-Hwan Kim3, Hae-Rahn Bae2,3,
Author Information & Copyright
1Dept. of Emergency Medicine, College of Medicine, Dong-A University, Busan 49201, Korea
2Dept. of Physiology, College of Medicine, Dong-A University, Busan 49201, Korea
3Human Life Research Center, Dong-A University, Busan 49315, Korea
Corresponding Author : Hae-Rahn Bae, Dept. of Physiology, College of Medicine, Dong-A University, Busan 49201, Korea. Tel: +82-51-240-2924, E-mail: hrbae@dau.ac.kr

* These authors contributed equally to this work.

© Copyright 2018 The Korean Society of Developmental Biology. This is an Open Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/3.0/) which permits unrestricted non-commercial use, distribution, and reproduction in any medium, provided the original work is properly cited.

Received: Jul 31, 2018 ; Revised: Aug 27, 2018 ; Accepted: Sep 10, 2018

Published Online: Sep 30, 2018

ABSTRACT

Aquaporin (AQP) 3, a facilitated transporter of water and glycerol, expresses in placenta and fetal membranes, but the detailed localization and function of AQP3 in placenta remain unclear. To elucidate a role of AQP3 in placenta, we defined the expression and cellular localization of AQP3 in placenta and fetal membranes, and investigated the structural and functional differences between wild-type and AQP3 null mice. Gestational sacs were removed during mid-gestational period and amniotic fluid was aspirated for measurements of volume and composition. Fetuses with attached placenta and fetal membranes were weighed and processed for histological assessment. AQP3 strongly expressed in basolateral membrane of visceral yolk sac cells of fetal membrane, the syncytiotrophoblasts of the labyrinthine placenta and fetal nucleated red blood cell membrane. Mice lacking AQP3 did not exhibit a significant defect in differentiation of trophoblast stem cells and normal placentation. However, AQP3 null fetuses were smaller than their control litter mates in spite of a decrease in litter size. The total amniotic fluid volume per gestational sac was reduced, but the amniotic fluid-to-fetal weight ratio was increased in AQP3 null mice compared with wild-type mice. Glycerol, free fatty acid and triglyceride levels in amniotic fluid of AQP3 null mice were significantly reduced, whereas lactate level increased when compared to those of wild-type mice. These results suggest a role for AQP3 in supplying nutrients from yolk sac and maternal blood to developing fetus by facilitating transport of glycerol in addition to water, and its implication for the fetal growth in utero.

Keywords: Aquaporin 3; Glycerol; Placenta; Fetal membrane; Amniotic fluid; Fetal growth

INTRODUCTION

Aquaporins (AQPs) are a family of small integral membrane proteins that primarily transport water across the cell membrane along osmotic gradients. Until now, 13 AQPs have been found in mammals (AQP0-12), some of which permit transcellular passage of glycerol and urea as well as water (AQP3, 7, 9, and 10) (Ishibashi et al., 2009; Verkman, 2011). AQP1, AQP3, AQP4, AQP8 and AQP9 have been reported to express in placenta and fetal membranes and suggested to play a key role in fetal fluid balance (Mann et al., 2002; Wang et al., 2006; Zhu et al., 2009). Mann et al. (2002) described increased amniotic fluid volume in AQP1 knock-out mice, speculating the association of AQP1 deficiency in fetal membranes with idiopathic polyhydramnios (Mann et al., 2005). Zhu et al. (2009) observed decreased expression of AQP1 and AQP3 in amnion of human term pregnancies with oligohydramnios as well as increased expression of AQP8 and AQP9 in polyhydramnios (Zhu et al., 2009; Jiang et al., 2012). Despite these reports, the precise role of AQPs in regulation of fetal fluid and electrolyte balance remains to be determined.

AQP3 is a water/glycerol transporting protein, which expresses in the basolateral membranes of epithelial cells in kidney collecting duct, airways, intestine and epidermis (Verkman, 2005). Mice lacking AQP3 manifest various degrees of nephogenic diabetes insipidus resulting from inability to concentrate the urine, and dry skin with decreased elasticity and impaired biosynthesis due to reduced glycerol and water content in epidermis (Ma et al., 2000; Hara et al., 2002). Based on the revealed function of AQP3 in other tissues, we speculated that AQP3 deficiency in placenta and fetal membranes might affect the fetal growth and development by changing the amniotic fluid volume and composition due to the defects in maternal-to-fetal transport of water and glycerol. However, the role of AQP3 in placenta has so far not been explored using mice lacking AQP3. Here, using AQP3 null mice, we showed that AQP3 deficiency in placenta and fetal membranes led to the intrauterine growth restriction.

MATERIALSA AND METHODS

1. Mice

AQP3 null mice generated by targeted gene disruption in embryonic stem cells in a CD1 genetic background were generously provided by Dr. Alan Verkman at University of California San Francisco, California, USA. The protocols for this study were approved by Dong-A University Medical School Institutional Animal Care Use Committee (DIACUC-07-20). Mice aged 8- to 12-week-old were used for this study. The presence of vaginal plug on the morning after mating was considered an evidence of successful copulation, and designated as 0.5 day post coitum (dpc). Timed pregnant mice were anesthetized and maternal blood was obtained from inferior vena cava. After the uterine horns were exposed by laparotomy, the whole gestational sacs were separated from the uterus, counted and weighed. Then, each gestational sac was isolated and weighed before and after aspiration of amniotic fluids. Amniotic fluid aspirated from 3 gestational sacs was pooled and stored at -70℃ for the chemical analysis. Finally, placenta, fetal membranes and fetuses were separated from each gestational sac and weighed individually. Amniotic fluid volume was calculated by subtracting the sum of weights of placental and fetal membrane, and fetus from that of a gestational sac.

2. Histology and immunohistochemistry

Gestational sacs were fixed in 10% neutral buffered formalin overnight, paraffin-embedded and sectioned at 5 μm. For histological evaluation of placenta and fetus, the paraffin sections were routinely stained with hematoxylin and eosin. For immunohistochemistry, paraffin sections were deparaffinized, rehydrated and antigen-retrieved in citrate buffer (10 mM sodium citrate, 0.05% Tween 20, pH 6.0) for 15 min at 100℃. After inactivation of endogenous peroxidase with 0.3% hydrogen peroxide, sections were incubated with 5% bovine serum albumin and 5% fetal bovine serum for 1 h at room temperature to block non-specific binding. Sections were incubated with primary antibodies; rabbit polyclonal anti-AQP1 (Chemicon, Temecula, CA, USA), anti-AQP3 (Chemicon, Temecula, CA, USA), and anti-AQP9 (Chemicon, Temecula, CA, USA) antibodies, overnight at 4℃. Subsequently, the sections were incubated with secondary anti-rabbit horseradish peroxidase linked IgG (Dako, Glostrup, Denmark) for 1 h at room temperature, and the reaction was visualized by DAB+ chromogen (Dako, Glostrup, Denmark). Tissue sections were mounted, and then visualized using digital scanning microscope (Scanscope, Aperio Technologies, Vista, CA, USA).

3. Immunofluorescence

Frozen sections were air-dried, fixed in ice-cold acetone and blocked with 5% bovine serum albumin. The sections were incubated with anti-AQP antibodies as described above, and then with Alexa Fluor 488- or 555-conjugated anti-rabbit IgG antibodies (Molecular Probes, Eugene, OR, USA). The sections were mounted with Vectashield anti-fade reagent containing DAPI (Vector Laboratories, Burlingame, CA, USA) and visualized using confocal microscopy (LSM 510, Carl Zeiss, Thornwood, NY, USA) or fluorescence microscopy (IX70, Olympus, Tokyo, Japan).

4. Chemical assay of amniotic fluid and plasma

Biochemical metabolic parameters in amniotic fluid and plasma were measured using commercially available kits according to the manufacturer’s protocols; for glucose by the hexokinase colorimetric assay kit (Sigma-Aldrich, Saint Louis, MO, USA), for glycerol by the glycerol assay kit (Sigma-Aldrich, Saint Louis, MO, USA), for triglyceride by the serum triglyceride determination kit (Sigma-Aldrich, Saint Louis, MO, USA), for lactate by the lactate assay kit (BioVision, Mountain View, CA, USA) and for FFA by the free fatty acid assay kit (Cell Biolabs, San Diego, CA, USA). Osmolality of serum and amniotic fluid was determined by freezing point method with Multi Osomometer (Precision System Inc., Natick, MA, USA). Electrolyte (Na, K and Cl) concentrations in amniotic fluid were determined by ion selective electrode method using Toshiba TBA 200FR (Toshiba Medical Systems Co., Ltd., Tokyo, Japan). Other chemical assays of amniotic fluids were done using automation system of diagnostic and laboratory medicine in Dong-A university.

5. Statistical analysis

All the data were expressed as mean±standard deviation. The statistical significance of differences between groups was analyzed by Mann-Whitney U t-test or one-way repeated measure ANOVA. Statistical significance was assumed at a value of p<0.05.

RESULTS

1. Expression and distribution of AQP3 in fetal membrane and placenta

In order to obtain the detailed information about the localization of AQP3 in placenta and fetal membrane, we first conducted immunohistochemistry and immunofluorescence using antibodies against different AQP subtypes. As shown in Fig. 1, AQP1 and AQP3 were abundantly expressed in placenta and fetal membrane showing a subtype-specific difference in subcellular localization. Anti-AQP3 antibody revealed strong labeling at the fetal-maternal interface in the labyrinthine region of placenta at E14.5 (Fig. 1A). AQP3 immunoreactivity was localized to the double-layered syncytiotrophoblasts of blood-placental barrier as well as the plasma membranes of fetal nucleated erythrocytes (Fig. 1B). The higher magnification image shows that AQP3 immunoreactivity was more restricted to the syncytiotrophoblast layer I (ST-1) facing maternal blood sinuses (Fig. 1D). In addition, AQP3 immunoreactivity was prominent in the basolateral membranes of visceral yolk sac endoderm as well as amniotic epithelium (Fig. 1C and E). However, no significant density of anti-AQP3 stain was detected in the mesodermal cells of visceral and parietal yolk sac. In contrast to AQP3, none of the three layers of trophoblasts composing the blood-placental barrier were immunoreactive for AQP1 (Fig. 1G and I). AQP1 immunoreactivity was detected at the plasma membranes of maternal rather than fetal red blood cells, and in endothelial cells lining both maternal and fetal blood vessels. In fetal membranes, AQP1 immunoreactivity was localized to the apical rather than basolateral membrane of visceral and parietal yolk sac endoderm as well as amnion (Fig. 1H and J).

dr-22-3-263-g1
Fig. 1. The expression and distribution of AQP3 in placenta and fetal membranes. (A-J) Immunohistochemistry of paraffin sections of E14.5 placenta and fetal membranes from wild-type CD1 mice using AQP3 (A-E) or AQP1 (F-J) antibodies with or without hematoxylin counterstain. Areas indicated by boxes in A and F were magnified in B-E and G-J, respectively. AQP3 immunoreactivity is observed at the plasma membrane of maternal-facing syncytiotrophblasts in fetal-maternal interface of the labyrinth (arrows in B and D), the basolateral membrane of visceral yolk sac endoderm (arrows in C and E) and fetal erythrocytes (arrowheads in C and E). F, fetal blood sinus; M, maternal blood sinus. AQP1 immunoreactivity is found in the plasma membrane of maternal erythrocytes (an arrowhead in I) and the apical membrane of visceral yolk sac endoderm (arrows in H and J). (K-T) Immunofluorescence staining for AQP3 (K-O) and AQP9 (P-T) using frozen sections of E9.5 placenta and fetal membranes. AQP3 immunoreactivity is detected in the fetal-maternal interface (arrows in K and L), fetal erythrocytes (an arrowhead in L), visceral yolk sac endoderm (arrows in K, M, and N) and amnion (an arrow in O). AQP9 immunoreactivity is found in the perimetrium (an arrow in P). Scale bars; 100 μm (A, F, K, P), 20 μm (the rest). AQP, aquaporin.
Download Original Figure

A distinct expression pattern of AQP3 in placenta and fetal membranes observed by immunohistochemistry was confirmed by immunofluorescence microscopy. An intense fluorescent anti-AQP3 signal was detected at the fetal-maternal interface of the labyrinth, the cell surface of fetal nucleated erythrocytes as well as the basolateral membrane of visceral yolk sac endodermal cells (Fig. 1K, L, M, and N). Amnion also displayed a low but detectable signal of anti-AQP3 (Fig. 1O). However, visceral yolk sac mesoderm, parietal yolk sac endoderm and endometrial epithelia were lack of AQP3 immunoreactivity. In contrast, AQP9 immunoreactivity was found neither at the fetal-maternal interface in the labyrinthine nor in visceral and parietal yolk sac (Fig. 1Q, R, S, and T). Only mesothelial cells of the perimetrium displayed a prominent AQP9 immunoreactivity (Fig. 1P).

2. Placental development and fetal growth of AQP3 knock-out mice

We examined whether AQP3 deficiency affects placental development through histological analysis of the placentas at E14.5 of AQP3 knock-out mice. Formation of chorioallantoic placenta appeared to be normal and three regions of decidua, the junctional zone and the labyrinth were well-recognized in AQP3-null mouse placentas as well as those of wild-type mice (Fig. 2A and B). Trophoblast giant cells, spongiotrophoblast cells and glycogen trophoblast cells were identified in the junctional zone, and three-cell-layered placental barrier developed normally in the labyrinth of AQP3-null mouse placenta (Fig. 2C, D, E, and F). In addition, the fetal membranes of AQP3 knock-out mice were also similar to those of wild-type mice; visceral yolk sac endoderm formed the villi near the placenta (Fig. 2G and H), and was transferred to microvilli-developed cuboidal cells of parietal yolk sac as it got farther away from placenta (Fig. 2I and J). There was no apparent histological defect observed during the development of placenta and fetal membrane due to AQP3 gene deficiency.

dr-22-3-263-g2
Fig. 2. Histological analysis of embryonic day 14.5 placentas from wild-type and AQP3 knock-out mice. (A, B) Cross sections of embryonic day 14.5 placentas from wild-type (+/+) and AQP3 knock-out (−/−) mice. Scale bar, 1 mm. (C-F) Higher magnifications of boxed areas in A and B, respectively. Labyrinth zone (C, D) and junctional zone (E, F). F, fetal blood sinus; M, maternal blood sinus. Scale bar, 20 μm. (G-J) periplacental (G, I) and distal (H, J) regions of fetal membrane. Visceral yolk sac endoderm cells (arrows) and amnion (arrowheads) are marked. F, vitelline vessels. Scale bar, 20 μm. AQP, aquaporin.
Download Original Figure
3. Fetal growth of AQP3 knock-out mice

We next investigated whether AQP3 deficiency affects pregnancy and embryonic development. AQP3 knock-out mice had higher pregnancy failure rate than wild-type mice (67.21% vs 14.71%, data not shown). In addition, number of fetuses in a pregnancy was reduced in AQP3 knock-out mice compared with that of wild-type mice (9.13±0.54 vs 10.92±0.35, p<0.05, Fig. 3A). In spite of the small number of gestational sacs, fetuses of AQP3 knock-out mice were smaller than those of wild-type mice (Fig. 3B). The height of the fetus at E14.5, measured by the crown-rump length (CRL), was significantly reduced in AQP3 knock-out mice (10.5±1.1 mm vs 13.4±2.0 mm, p<0.05). AQP3 knock-out fetuses had lower body weight than wild-type fetuses regardless of the embryonic days during pregnancy. The difference in the weights between AQP3 knock-out and wild-type fetuses was highest on E14.5 (0.24±0.02 g vs. 0.43±0.03 g, p<0.05), showing a 44% reduction compared to the wild-type control (Fig. 3C). Although the difference in fetal weights reduced to 21% in the late gestation at E16.5, AQP3 knock-out fetuses still exhibited lower body weights at birth than did the wild-type fetuses (1.21±0.07 g vs. 1.53±0.09 g, p<0.05).

dr-22-3-263-g3
Fig. 3. Fetal growth of AQP3 knock-out mice. (A) Number of fetuses per pregnancy of wild-type (+/+) and AQP3 knock-out (-/-) mice. (B) Gross appearance of 14.5-dpc fetuses. The AQP3 -/- fetus is smaller than a wild-type littermate. (C) Body weights of wild- type and AQP3 knock-out fetuses and pups. Values are mean±SE. *p<0.05, AQP3+/+ vs. AQP3-/- mice. AQP, aquaporin.
Download Original Figure
4. Amniotic fluid volume and composition of AQP3 knock-out mice

To determine whether AQP3 deficiency influences the amount and composition of amniotic fluid, we measured amniotic fluid volume directly at the different stages of development. The volume of amniotic fluid per gestational sac gradually increased during pregnancy. However, there was no significant difference in total amount of amniotic fluid in each gestational sac between AQP3 knock-out and wild-type mice (Fig. 4A). When the amniotic fluid volume was normalized to average weight of fetus considering the lower body weight of AQP3 knock-out mice than wild-type mice, it increased significantly during early to mid-gestation in AQP3 knock-out mice compared with wild-type mice (Fig. 4B). The biggest difference in amniotic fluid volume between AQP3 knock-out and wild-type mice was observed at E14.5 (0.60±0.02 mL vs. 0.35±0.03 mL, p<0.05), whereas the amniotic fluid volume of AQP3 knock-out mice became similar to that of wild-type mice during late gestation (E16.5).

dr-22-3-263-g4
Fig. 4. Amniotic fluid volume of AQP3 knock-out mice during the mid-gestational period. (A) Total amount of amniotic fluid (AF) in each gestational sac of wild-type (+/+) and AQP3 knock-out (-/-) mice. (B) Average weight-normalized AF volume of AQP3 +/+ and -/- mice. Values are mean±SE. *p<0.05, AQP3+/+ vs. AQP3-/- mice. AQP, aquaporin.
Download Original Figure

We measured the concentrations of metabolic substrates in amniotic fluid of AQP3 knock-out mice at E14.5. Concentrations of the metabolites measured were all reduced except lactate. Glycerol concentration in amniotic fluid showed the biggest difference between wild-type and AQP3 knock-out mice (6.69 mg/dL vs. 4.33 mg/dL, 1.54 fold decrease, p<0.01, Fig. 5A). The levels of triglyceride and free fatty acids in amniotic fluid were also low in AQP3 knock-out mice compared to wild-type mice (1.38 fold and 1.36 fold decrease, respectively, Fig. 5B and C). The glucose concentration in amniotic fluid was also decreased in AQP3 knock-out mice, but with a less difference between the two groups (81.10 mg/dL vs. 72.23 mg/dL, 1.12 fold decrease, p<0.01, Fig. 5D). However, the lactate concentration in amniotic fluid of AQP3 knock-out mice was much higher than that of wild-type mice (1.52 mM vs. 2.18 mM, 1.43 fold decrease, p<0.01, Fig. 5E).

dr-22-3-263-g5
Fig. 5. Concentrations of metabolic substrates in amniotic fluid. Amniotic fluid was harvested from wild-type (+/+) and AQP3 knock-out (-/-) mice on the embryonic day 14.5. The concentrations of glycerol (A), free fatty acid (B), triglyceride (C), glucose (D) and lactate (E) were measured. Values are mean±SE. **p<0.01, AQP3+/+ vs. AQP3−/− mice. AQP, aquaporin.
Download Original Figure

DISCUSSION

We conducted this study in order to investigate the role of AQP3 in placenta and fetal membranes using AQP3 knockout mice. We found that AQP3 knockout mice exhibited intrauterine growth restriction as well as decreased metabolite concentrations in amniotic fluid. However, AQP3 knockout mice did not display hydroamnios or oligohydroamnios, although the amniotic fluid-to-fetal weight ratio increased in AQP3 null mice compared with wild-type mice.

The presence of AQP1, AQP3, AQP4, AQP8 and AQP9 transcripts and proteins have been described in placenta and fetal membranes (Liu et al., 2008; Hua et al., 2013). AQP1 expresses in the epithelial cells of chorionic plate amnion as well as endothelial cells in placenta and yolk sac of both human and mouse (Zhu et al., 2009). AQP3, AQP8 and AQP9 localize not only in epithelial cells of amnion but also in cytotrophoblasts and syncytiotrophoblasts of placenta in human (Damiano et al., 2001), whereas AQP4 is reported to express in stroma of human placenta (De Falco et al., 2007). In mice, AQP3 expression in amnion and trophoblasts of the labyrinth has been demonstrated (Kobayashi & Yasui, 2010). Here we first described the expression of AQP3 in the basolateral membranes of visceral yolk sac endoderm. We also determined the precise localization of AQP3 in the basolateral membrane of epithelial cells in amnion and the syncytiotrophoblast facing maternal blood sinuses in the labyrinth. In addition, AQP1 localization at the apical membrane of epithelial cells of both amnion and visceral yolk sac endoderm was also first described. Inconsistently with the previous reports (Damiano et al., 2001; Kobayashi & Yasui, 2010), AQP9 expression was not observed either in amnion or placenta except mesothelial cells of the perimetrium.

Development of placenta and fetal membrane is essential for normal fetal growth (Cross et al., 1994). Placenta provides vascular connections necessary for nutrient transport as well as attachment of the embryo to uterus. In mammals, two different types of placenta develop, yolk sac placenta (choriovitelline placenta) and chorioallantoic placenta (Carter, 2007). The yolk sac placenta formed in early pregnancy provides nourishment to the developing embryo until a definitive chorioallantoic placenta is established, then undergoing degeneration in human. Although striking differences in structure and function of the placenta are present among species, human and mouse placentas show structural similarities in terms of a highly invasive hemochorial type (Rossant & Cross, 2001; Cross et al., 2003; Enders & Carter, 2006). A comparative proteomic and transcriptomic investigation of placental tissues from both species revealed that over 80% of genes known to cause placental phenotypes in mouse are co-expressed in human (Cox et al., 2009). However, the number of trophoblast layers interposed between the maternal blood space and fetal capillaries is different between human and mouse. Human placenta is hemomonochorial with a single layer of syncytiotrophoblast adjacent to fetal endothelial cells, while the mouse placenta is hemotrichorial containing two syncytiotrophoblast layers and one cytotrophoblast layer in the placental barrier (Carter, 2007). We described here that AQP3 is strongly expressed in the syncytiotrophoblast in chorioallantoic placenta, an epithelium responsible for materno-fetal substrate transfer. Glucose (GLUT1 -3 and -4) and amino acid transporters (SNAT1, -2, and -4) have also been demonstrated to express at the microvillous and basal membranes of the syncytiotrophoblast in human placenta (Takata et al., 1994; Novak & Beveridge, 2000). Therefore, AQP3-mediated glycerol transport across the syncytiotrophoblast in placental barrier seems to be rate-limiting in embryo transfer and so do sugar and amino acids.

The yolk sac, which comprises both endoderm and mesoderm layers, is also a true placenta crucial for early embryonic development and survival in both human and mouse (Freyer & Renefree, 2008). The yolk sac serves as the only hematopoietic organ in early pregnancy and involves vasculogenesis, which is essential to fulfil its basic function as gas exchange and nutrient supply (Palis & Yoder, 2001). As the eutherian yolk sac essentially lacks nutrients inside the sac unlike that of an oviparous organism, maternal nutrients originating from the exocoelomic cavity or uterine glandular secretion are transferred to the growing embryo through the yolk sac. Uterine nutrients enter the yolk sac by passing through the trophoblasts, the parietal yolk sac endoderm cells and Reichert’s membrane formed between these cell layers vasculature (Sheng & Foley, 2012). Once inside the exocoelomic cavity, maternal nutrients are taken up by the visceral yolk sac endoderm and transported to the embryo through the vitelline. In the yolk sac-mediated route of nutrient transfer, the visceral yolk sac endoderm is the principal interface for nutrient uptake (Maurer & Cooper, 2005). Furthermore, the visceral yolk sac endoderm synthesizes cholesterol de novo and secretes serum proteins including apolipoprotein B (apoB)-containing lipoproteins, which play an essential role in lipid transport to the fetus (Plonne et al., 1992; Madsen et al., 2004). In this paper, we observed strong AQP3 expression in basolateral membrane of the visceral yolk sac endoderm, which is a key player in maternal-to-fetal nutrient transfer through yolk sac. Considering this with the finding of high AQP3 expression at the cell surface of fetal erythrocytes, we speculate that AQP3-mediated glycerol transport through yolk sac is highly activated in early pregnancy and presumably required for backbone of lipid or energy source to rapidly developing embryo.

Amniotic fluid provides an ideal environment for normal fetal growth (Brace, 1997). During mid to late gestation, amniotic fluid is produced from fetal urine and lung fluid, and removed by fetal swallowing and intramembranous absorption (Beall et al., 2007). AQPs in placenta and fetal membranes have been proposed to regulate the amniotic fluid volume. Alterations in their expression levels in placenta and fetal membranes have been reported to be related to polyhydramnios and oligohydramnios. It was demonstrated that AQP1 null mice exhibited polyhydroamnios and that AQP1 expression was increased in human placenta with idiopathic polyhydramnios (Mann et al., 2005). Alterations of AQP3, AQP8 and AQP9 expressions in fetal membrane were also reported in idiopathic polyhydramnios (Zhu et al., 2010). However, contrary to our assumption, we observed that AQP3 knock-out mice did not display polyhydramnios. We speculated that AQP3-mediated water transport across the basolateral membrane of amnion epithelial cells might be replaced with other AQPs present in the same membrane domain, whereas water reabsorption across the apical membrane of amnion epithelial cells and subsequently to blood vessels beneath through AQP1 cannot be substituted by any other AQPs. In addition, inability to concentrate the urine in AQP3 knock-out fetus did not seem to contribute to an increase in the amniotic fluid volume presumably due to no necessity for concentrating urine in fetal life floated in amniotic fluid.

Maternal triglycerides have been suggested as a primary source of fatty acids and glycerol because of their substantial increase in mid- to late gestation (Herrera, 2002). As maternal triglycerides cannot directly cross the placental barrier, they are either hydrolyzed into free fatty acids and glycerol by lipoprotein lipase (LPL) and endothelial lipase (EL) in microvillous membrane or taken up by syncytiotrophoblasts via a receptor-mediated endocytosis as incorporated into lipoproteins (Gil-Sanchez et al., 2011). FFA transport across the plasma membrane, apical or basal., occurs either by a simple diffusion through lipid bilayer or by facilitated diffusion using a fatty acid translocase (FAT/CD36), a fatty acid transport protein (FATP) and plasma membrane fatty acid-binding protein (FABPpm) for the uptake of long chain polyunsaturated fatty acids (Schaffer & Lodish, 1994). FAT/CD36, five members of FATPs (FATP1-4, and 6) and FABPpm have been identified in placental trophoblasts (Campbell et al., 1998).

Whereas considerable studies have been carried out on FFA transport across placenta, little attention was paid on the glycerol transfer from mother to fetus. Glycerol released along with FFA during triglyceride hydrolysis is either passively diffused across the cell membrane or transported by a facilitated diffusion through aquaglyceroporins to enter fetal circulation. Based on our findings of AQP3 localization in the syncytiotrophoblast of chorioallantoic placenta and basolateral membrane of endoderm of visceral yolk sac as well as low amniotic fluid glycerol concentration in AQP3 knock-out mice, we speculated that AQP3-mediated glycerol transport across the syncytiotrophoblast in placental barrier and endoderm of visceral yolk sac seems to be a rate-limiting step in glycerol transfer of embryo. Glycerol is used as a backbone of phospholipids or a source of energy during fetal development. Glycerol is a precursor of glucose and enters the gluconeogenic pathway as dihydroxyacetone phosphate in order to be converted into glucose (Klein et al., 1990).

AQP3 knockout mice exhibited intrauterine growth restriction along with decreased concentrations of metabolite substrates including glycerol in amniotic fluid. During embryonic development, especially the second half of gestation when energetic and biosynthetic demand increases rapidly to support the exponential rate of fetal growth, mobilization of maternal fat stores is accelerated (Herrera et al., 2006). Decrease in maternal glycerol delivery to fetus due to the AQP3 deficiency despite increasing demand during the second half of gestation might explain the reduced growth rate of AQP3 knockout pups to some extent.

In conclusion, this study is the first to demonstrate that AQP3 deficiency in placenta and fetal membranes is associated with reduced metabolite concentrations in amniotic fluid and impaired fetal growth. Our findings that AQP3 plays an important role in supplying glycerol from yolk sac and maternal blood to developing fetus in mice and that glycerol and its transporter, AQP3 might be implicated in normal fetal growth in human pregnancy.

ACKNOWLEDGEMENTS

We are grateful to Dr Alan Verkman (UCSF, San Francisco, California, USA) for providing AQP3 knockout mice. This work was supported by the Dong-A University research fund.

REFERENCES

1.

Beall MH, van den Wijngaard JPHM. MJC van GemertRoss MG. 2007; Amniotic fluid water dynamics. Placenta. 28:816-823

2.

Brace RA. 1997; Physiology of amniotic fluid volume regulation. Clin Obstet Gynecol. 40:280-289

3.

Campbell FM, Bush PG, Veerkamp JH, Dutta-Roy AK. 1998; Detection and cellular localization of plasma membrane-associated and cytoplasmic fatty acid-binding proteins in human placenta. Placenta. 19:409-415

4.

Carter AM. 2007; Animal models of human placentation-A review. Placenta. 28:S41-S47

5.

Cox B, Kotlyar M, Evangelou AI, Ignatchenko V, Ignatchenko A, Whiteley K, Jurisica I, Adamson SL, Rossant J, Kislinger T. 2009; Comparative systems biology of human and mouse as a tool to guide the modeling of human placental pathology. Mol Syst Biol. 5:279

6.

Cross JC, Simmons DG, Watson ED. 2003; Chorioallanoic morphogenesis and formation of the placental villous tree. Ann N Y Acad Sci. 995:84-93

7.

Cross JC, Werb Z, Fisher SJ. 1994; Implantation and the placenta: Key pieces of the development puzzle. Science. 266:1508-1518

8.

Damiano A, Zotta E, Goldstein J, Reisin I, Ibarra C. 2001; Water channel proteins AQP3 and AQP9 are present in syncytiotrophoblast of human term placenta. Placenta. 22:776-781

9.

De Falco M, Cobellis L, Torella M, Acone G, Varano L, Sellitti A, Ragucci A, Coppola G, Cassandro R, Laforgia V, Varano L, De Luca A. 2007; Down-regulation of aquaporin 4 in human placenta throughout pregnancy. In Vivo. 21:813-817

10.

Enders AC, Carter AM. 2006; Comparative placentation: Some interesting modifications for histotrophic nutrition-A review. Placenta. 27:S11-S16

11.

Freyer C, Renfree MB. 2008; The mammalian yolk sac placenta. J Exp Zoolog B Mol Dev Evol. 312B:545-554.

12.

Gil-Sanchez A, Demmelmair H, Parrilla JJ, Koletzko B, Larque E. 2011; Mechanisms involved in the selective transfer of long chain polyunsaturated fatty acids to the fetus. Front Genet. 2:57

13.

Hara M, Ma T, Verkman AS. 2002; Selectively reduced glycerol in skin of squaporin-3-deficienct mice may account for impaired hydration, elasticity, and barrier recovery. J Biol Chem. 227:46616-46621.

14.

Herrera E. 2002; Lipid metabolism in pregnancy and its consequences in the fetus and newborn. Endocrine. 19:43-45

15.

Herrera E, Amusquivar E, Lopez-Soldado I, Ortega H. 2006; Maternal lipid metabolism and placental lipid transfer. Horm Res Paediatr. 65:59-64.

16.

Hua Y, Jiang W, Zhang W, Shen Q, Chen M, Zhu X. 2013; Expression and significance of aquaporins during pregnancy. Front Biosci. 18:1373-1383.

17.

Ishibashi K, Hara S, Kondo S. 2009; Aquaporin water channels in mammals. Clin Exp Nephrol. 13:107-117

18.

Jiang SS, Zhu XJ, Ding SD, Wang JJ, Jiang LL, Jiang WX, Zhu XQ. 2012; Expression and localization of aquaporins 8 and 9 in term placenta with oligohydramnios. Reprod Sci. 19:1276-1284

19.

Klein S, Holland OB, Wolfe RR. 1990; Importance of blood glucose concentration in regulating lipolysis during fasting in humans. Am J Physiol. 258:E32-E39

20.

Kobayashi K, Yasui M. 2010; Cellular and subcellular localization of aquaporins 1, 3, 8, and 9 in amniotic membranes during pregnancy in mice. Cell Tissue Res. 342:307-316

21.

Liu H, Zheng Z, Wintour EM. 2008; Aquaporins and fetal fluid balance. Placenta. 29:840-847

22.

Ma T, Song Y, Yang B, Gillespie A, Carlson EJ, Epstein CJ, Verkman AS. 2000; Nephogenic diabetic insipidus in mice lacking aquaporin-3 water channels. Proc Natl Acad Sci U.S.A. 97:4386-4391

23.

Madsen EM, Lindegaard MLS, Andersen CB, Damm P, Nielsen LB. 2004; Human placenta secretes apolipoprotein B-100-containing lipoproteins. J Biol Chem. 275:55271-55276.

24.

Mann SE, Ricke EA, Torres EA, Tayilor RN. 2005; A novel model of polyhydramnios: Amniotic fluid volume is increased in aquaporin 1 knock-out mice. Am J Obstet Gynecol. 192:2041-2046

25.

Mann SE, Ricke EA, Yang BA, Verkman AS, Taylor RN. 2002; Expression and localization of aquaporin 1 and 3 in human fetal membranes. Am J Obstet Gynecol. 187:902-907

26.

Maurer ME, Cooper JA. 2005; Endocytosis of megalin by visceral endoderm cells requires the Dab2 adaptor protein. J Cell Sci. 118:5345-5355

27.

Novak DA, Beveridge MJ. 2000; Anionic amino acid transporter expression in late gestation rodent yolk sac. Placenta. 21:834-839

28.

Palis J, Yoder MC. 2001; Yolk-sac hematopoiesis: The first blood cells of mouse and man. Exp Hematol. 29:927-936

29.

Plonne D, Winkler L, Franke H, Dargel R. 1992; The visceral yolk sac-an important site of synthesis and secretion of apolipoprotein B containing lipoproteins in the feto-placental unit of the rat. Biochim Biophys Acta. 1127:174-185

30.

Rossant J, Cross JC. 2001; Placental development: Lessons from mouse mutants. Nat Rev Genet. 5:538-548.

31.

Schaffer JE, Lodish HF. 1994; Expression cloning and characterization of a novel adipocyte long chain fatty acid transport protein. Cell. 79:427-436

32.

Sheng G, Foley AC. 2012; Diversification and conservation of the extraembryonic tissues in mediating nutrient uptake during amniote development. Ann NY Acad Sci. 1271:97-103

33.

Takata K, Kasahara T, Kasahara M, Ezaki O, Hirano H. 1994; Immunolocalization of glucose transporter GLUT1 in the rat placental barrier: Possible role of GLUT1 and the gap junction in the transport of glucose across the placental barrier. Cell Tissue Res. 276:411-418

34.

Verkman AS. 2005; Novel roles of aquaporins revealed by phenotype analysis of knock-out mice. Rev Physiol Biochem Pharmacol. 155:31-55

35.

Verkman AS. 2011; Aquaporins at a glance. J Cell Sci. 124:2107-2112

36.

Wang F, Feng XC, Li YM, Yang H, Ma TH. 2006; Aquaporins as potential drug targets. Acta Pharmacol Sin. 27:395-401

37.

Zhu XQ, Jiang SS, Zhu XJ, Zou SW, Wang YH, Hu YC. 2009; Expression of aquaporin 1 and aquaporin 3 in fetal membranes and placenta in human term pregnancies with oligohydramnios. Placenta. 30:670-676

38.

Zhu X, Jiang S, Hu Y, Zheng X, Zou S, Wang Y, Zhu X. 2010; The expression of aquaporin 8 and aquaporin 9 in fetal membranes and placenta in term pregnancies complicated by idiopathic polyhydramnios. Early Hum Dev. 86:657-663
